New SGA-60
Key Facts
- Frequency range: 9 kHz to 6 GHz
- Maximum level output: 7 dBm to 14 dBm
- Minimum level output: < -100 dBm
- Level output up to 25 dBm (opt.)
- 1 GHz phase noise: < -124 dBc/Hz@10 kHz
- Maximum real-time bandwidth: 50 MHz
- Maximum playback output bandwidth: 100 MHz
- 0 dBm output harmonics: <-50 dBc (typ.)
Available Models
SGA-60
9 kHz – 6 GHz
9 kHz – 6 GHz
Options
Code
Option
Description
01
Built-in OCXO reference clock
built-in hardware
05
Internal high precision GNSS
built-in hardware
40
T1 temperature class
built-in hardware
41
T2 temperature class, only available for core
built-in hardware
